MAINLY USED IN
Mining
Mining/Quarry
OPERATING WEIGHT
18,900 kg
BUCKET CAPACITY (SAE HEAPED)
3.5 m³
ENGINE POWER (SAE J1995 GROSS)
178 kW (240PS) @ 2,000 rpm
PRODUCTIVITY & PERFORMANCE
· The perfect blend of efficiency and power. The engine produces 178 kW at rated rpm. High power and impressive torque range enables to precisely deliver the stable working speed.
· With 3,400mm wheel-base and small turning radius of 6,058mm, designed for greater agility of movement and more efficient operation.
REASONABLE AND PRACTICAL VETERAN
· Hydraulic system adopts double-pump confluence technology to make full use of power and energy.
NEW LOOK & ENHANCED STRUCTURE
· Applied new look with streamlined appearance and reinforced structure. With newly added LED lamp, SD350-2'S design represent a bold and functional brand style.
RELIABILITY AND DURABILITY
· The advanced DEVELON drive axle and improved differential gear process have increased gear flexural strength, enhanced the reliability of the drive axle and extended its lifespan.
OPERATOR COMFORT
· Newly designed cabin is spacious and provides wider view and enhanced safety, with low noise & vibration levels and excellent all-round visibility.
| Classification | SD350-2 |
|---|---|
| Operating Weight | 18,900 kg |
| Bucket Capacity (SAE HEAPED) | 3.5 m³ |
| Engine Power (SAE J1995 Gross) | 178 kW (240PS) @ 2,000 rpm |
| Engine Model | Weichai WP10G240E343 |
| Height at Bucket Pivot Point | 4,303 mm |
| Breakout Force | 197 kN |
| Turning Radius at Tire Center | 6,058 mm |
| Tires | 23.5-25-20PR |
| Overall Length | 8,540 mm |
| Overall Width | 3,035 mm |
| Overall Height | 3,450 mm |
| Static Tipping Load(straight) | 14,800 kg |
| Classification |
|---|
| Operating Weight |
| Bucket Capacity (SAE HEAPED) |
| Engine Power (SAE J1995 Gross) |
| Engine Model |
| Height at Bucket Pivot Point |
| Breakout Force |
| Turning Radius at Tire Center |
| Tires |
| Overall Length |
| Overall Width |
| Overall Height |
| Static Tipping Load(straight) |
| SD350-2 |
|---|
| 18,900 kg |
| 3.5 m³ |
| 178 kW (240PS) @ 2,000 rpm |
| Weichai WP10G240E343 |
| 4,303 mm |
| 197 kN |
| 6,058 mm |
| 23.5-25-20PR |
| 8,540 mm |
| 3,035 mm |
| 3,450 mm |
| 14,800 kg |
